Description
WIRES Wedge Wire Filter Disc
The WIRES wedge wire filter disc is a rigid, self-supporting circular screen constructed from precision V-shaped wedge wire (profile wire) resistance-welded to transverse support rods. Unlike woven wire mesh, the wedge wire design creates a continuous, non-clogging slot opening that widens outward, allowing captured particles to pass through or be easily back-flushed without blind spots. This makes it the ideal filter medium for viscous, particle-laden fluids such as waxy crude oil, heavy fuel oil, pulp stock, and wastewater. The discs are manufactured to exact diameters and slot widths, and can be stacked in multiple layers to achieve multi-stage filtration within a single housing.
Key Features
- V-shaped wedge wire slots widen outward — no particle bridging or blinding during back-flush
- Rigid self-supporting structure handles high differential pressure without deformation
- Precision slot openings from 20 μm to 3 mm for coarse or fine separation
- All 316L stainless steel construction resists seawater, HFO, and chemical corrosion
- Stackable multi-disc configurations enable multi-stage filtration in one housing
Specifications
| Parameter | Value |
|---|---|
| Slot Opening | 20, 25, 50, 75, 100, 150, 200, 300 μm (custom) |
| Material | 304 / 316L / 2205 duplex stainless steel |
| Disc Diameter | 50–500 mm (custom) |
| Disc Thickness | 2–8 mm |
| Operating Temperature | Up to 300 °C |
| Maximum Pressure | 1.6 MPa |
| Edge Type | Welded rim, bolt holes, or gasket groove |
Cross Reference
Interchangeable with: Johnson Screens, VAF Filters, Helly Harding, and Mercedes Marine self-cleaning filter discs. Custom diameters, slot widths, and center hole patterns fabricated to drawing.
Applications
- Marine engine self-cleaning back-flush filters (VAF, Alfa Laval, Mercedes)
- Basket strainers and T-strainer replacement screens
- Waxy crude and heavy fuel oil pre-filtration
- Pulp and paper stock chest dilution and shower water filtration
- Wastewater and seawater intake screening
- Liquidized bed support plates and gas distributors
About WIRES Filters
With over 28 years of specialized manufacturing experience, WIRES is a trusted OEM/ODM supplier of industrial filter elements and filtration systems for global B2B markets. Every filter is produced under strict quality control at our ISO-certified production facility, using premium raw materials sourced from trusted global suppliers. We offer full customization — including custom dimensions, media grades, end-cap configurations, and cross-reference matching to all major OEM brands. Our products are exported worldwide to power plants, chemical processing plants, food and beverage facilities, pharmaceutical manufacturers, marine operators, and hydraulic equipment users. Contact our engineering team today to request a quote or discuss your custom filtration requirements.
